Part

VH200-F10

Pre-Filter Solution:Adds integral 5 micron pre-filtration module to the VH200 UV system. Convenient:Mounted on a reversible, heavy duty, painted steel bracket for installation flexibility and…

VH200-F10

Product Images

VH200-F10 β€” image 2
VH200-F10 β€” image 3
VH200-F10 β€” image 4
VH200-F10 β€” image 5
VH200-F10 β€” image 6
VH200-F10 β€” image 7
1 / 6

Product Description

Pre-Filter Solution:Adds integral 5 micron pre-filtration module to the VH200 UV system. Convenient:Mounted on a reversible, heavy duty, painted steel bracket for installation flexibility and convenience Ease of Maintenance:Audible lamp replacement reminder and countdown timer with digital display. Controller will also go into alarm if the lamp fails Reliable:The constant current feature ensures stable UV lamp output, regardless of power fluctuations High-performance UV lamp, rigorously tested to provide consistent output over the entire lamp life (9000 hours) Space Efficient:High UV output lamp technology allows for a smaller footprint, while maintaining the same UV performance as a longer chamber. Powerful, yet compact UV system with pre-filtration designed for the average size home or cottage, for flow rates up to 9 gpm (34 lpm). The VH200-F10 inactivates the following microorganisms: Cryptosporidium, Giardia, E.Coli and Fecal Coliform.

Flow Rates > 16mJ/cm 216 GPM (60 lpm) (3.6 m 3 /hr)
Flow Rates > 30mJ/cm 29 GPM (34 lpm) (2.0 m 3 /hr)
Flow Rates > 40mJ/cm 27 GPM (26 lpm) (1.6 m 3 /hr)
Dimensions17β€³ x 10 1/2β€³ x 18β€³ (43 cm x 26 cm x 45 cm)
Shipping Weight lbs (kg)26 lbs (11.8 kg)
Connection Size1β€³MNPT INLET / 1β€³ x 3/4β€³ COMBO OUTLET (/2B – BSP)
Power Consumption35W

Models

Model and part-number options for VH200-F10 are available by request.

Features

Feature details for VH200-F10 can be shared on request.

Applications

Typical applications for VH200-F10 include industrial, commercial, and municipal water treatment β€” contact our team for project-specific guidance.
