Due to the requirements of high quality water in many industries, Pure Aqua has developed the RC-6500 Series. The Pure Aqua RC-6500 Series ion exchange filters provide high quality water in low volumes for specialized uses.
The cartridges have been developed in response to the requirements fordeionized waterin many industries. These high-capacity semi conductor grade resin cartridges are ideal for use in pharmaceutical and medical,laboratories, cosmetic and circuit board and printing applications.
The cartridges are available in three sizes, flow rates and capacities, they are convenient and cost effective for many applications where low levels of total organic carbon (TOC) and total dissolved solids are required.
They are manufactured using resin that has been subjected to additional post production steps to minimize the total organic carbon (TOC) level. The Softening or Deionizing Cartridges are designed for deionizing water, and all meterials and construction are FDA Compliant.
Here at Pure Aqua, Inc., we engineer and build all of our water treatment systems in-house.
Our turn-key water treatment systems are all pre-engineered using the latest CAD technology available.
This enables our teams to build and deliver treatment systems to our customers with quick turnaround times.
Many of our customers require custom engineered systems. These are typically built around similar core systems and thus allowing for improved turnaround times, even for one-off designs.
Models
Models
| Model# | RCS Models | RCD Models | ||||||
|---|---|---|---|---|---|---|---|---|
| (Softening Ion Exchange Systems) | (Deionizing Ion Exchange Systems) | |||||||
| RCS-10 | RCS-20 | RCS-10BB | RCS-20BB | RCD-10 | RCD-20 | RCD-10BB | RCD-20BB | |
| Housing Model | H-1034-BL | H-2034-BL | BBH-1010 | BBH-2015 | H-1034-BL | H-2034-BL | BBH-1010 | BBH-201 |
| Housing Size | 2.5"x10" | 2.5"x20" | 4.5"x10" | 4.5"x20" | 2.5"x10" | 2.5"x20" | 4.5"x10" | 4.5"x20" |
| Cartridge Model | SFT-10 | SFT-20 | SFT-10-B | SFT-20-B | DI-10 | DI-20 | DI-10-B | DI-20-B |
| Cartridge Size | 2.5"x10" | 2.5"x20" | 4.5"x10" | 4.5"x20" | 2.5"x10" | 2.5"x20" | 4.5"x10" | 4.5"x20" |
| Capacity (Grains) | 750 | 1000 | 1500 | 4500 | 450 | 900 | 1050 | 2350 |
| Flow Rage (GPM) | 0.3 | 0.5 | 0.8 | 1.25 | 0.3 | 0.5 | 0.8 | 1.25 |
| Max. Pressure Inlet (Psi) | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| Temperature Range (°F) | 45 to 100 | 45 to 100 | 45 to 100 | 45 to 100 | 45 to 100 | 45 to 100 | 45 to 100 | 45 to 100 |
| Diameter (Inch) | 5 1/3 | 5 1/3 | 8 | 8 | 5 1/3 | 5 1/3 | 8 | 8 |
| Height (Inch) | 13 | 28 | 13 | 28 | 13 | 28 | 13 | 28 |
| Weight (lbs) | 8 | 15 | 22 | 28 | 8 | 15 | 22 | 28 |
| For more information, please view/download our "Data Sheet" | ||||||||
