Product Description
9876tyPure Aqua offers top-notch water softeners that can provide clean water for your industrial applications. Our industrial water softeners have helped hundreds of clients eliminate water hardness problems on important equipment such as boiler feeds, cooling towers, heat-exchangers, etc.
Pure Aqua's industrial water softeners treat the water byremoving hardness using resin. The resin replaces the hardness in the water with salt which is regenerated periodically. The softened water can then pass through an RO system to remove the salt without the risk of scaling. Softeners can be used in a variety of services including: industrial, municipal, and institutional applications.
An Industrial water softener is sized on the basis of two different parameters:
Pure Aqua supplies a full line of standard and fully customizable water softener systems, all of which are engineered using advanced 3D computer modeling software for accurate and customized solutions, and we have several satisfied clients all around the world that use our industrial water softener solutions.
Here at Pure Aqua, Inc., we engineer and build all of our water treatment systems in-house.
Our turn-key water treatment systems are all pre-engineered using the latest CAD technology available.
This enables our teams to build and deliver treatment systems to our customers with quick turnaround times.
Many of our customers require custom engineered systems. These are typically built around similar core systems and thus allowing for improved turnaround times, even for one-off designs.
Models
Features
- Electrical: 120VAC, 1-Phase, 60 Hz, 5 Amp
- Steel tank with 100 psi rating
- NSF interior epoxy coated and primed exterior
- Top loading port or manway
- Schedule 80 PVC face piping
- Vent and drain ports
- 1β-2β Noryl diaphragm valves or butterfly valves for3ββ or larger
- Digital stager for softeners using diaphragmvalves or PLC for butterfly valves
- Fully automatic units with timer control, thatinitiates regeneration at any pre-determined time
- Regeneration cycle is fully adjustable and featuresup to 15 programmable timed regeneration cycle
- A premium high capacity, cation exchange resinthat will deliver 30,000 gr/ft3 when brined at a rateof 15 lbs./ft3
- Polyethylene brine tank assembly
- 1/4β tubing between stager and valves
- PVC sch 80 internal piping and distributor toevenly distribute water and prevent resin loss
- 240V/1ph/50Hz power requirement (optional)
- Duplex, triplex or multi units (optional)
- Skid mounted, plumbed, and wired systems (optional)
- ASME coded resin tanks (optional)
- Stainless steel, galvanized iron or CPVC face piping (optional)
- Meter regeneration starts based on the totalgallons used (optional)
- PLC control system (optional)
- Brine pump systems (optional)
- Stainless steel internal piping (optional)
- Butterfly control valves (optional)
- Inline hardness monitor (optional)
- Unistrut channel supports (optional)
